Bell 61 / HSL-1 helicopter

- Advertisement -
Choose unit system:

Specifications Comment this helicopter
Picture 61__HSL-1
General
Manufacturer Bell
Type 61 / HSL-1
Introduced 1/1/1957
In production? No
Units produced 53
Price US $ 0.00
Dimensions
Overall Length 0 ft
Length 39.04 ft
Height 14.5 ft
Width 0 ft


Description

The Bell HSL (Model 61) was an anti-submarine helicopter created by the Bell Helicopter company. It first took flight in 1953 and was introduced four years later in 1957.

The 1950s were a time when an urgent need for anti-submarine helicopters became apparent as both the USA and USSR engaged in the Cold War. The US navy held a design competition for such a helicopter and in 1950 Bell’s Model 61 was announced as the winner. Following this, three evaluation models were ordered. These were designated XHSL-1.

The Model 61 had a rectangular-section fuselage. It was powered by a massive single Pratt & Whitney R-2800 radial engine. The crew complement consisted of two pilots and two sonar operators. The landing gear consisted of a four-leg and six-wheel design.

The helicopter was meant to carry air-to-sea missiles and dipping sonar.

At the time the HSL was produced, it’s tandem-rotor design was the largest US helicopter example. It’s notable as being the only tandem-rotor helicopter Bell ever made.

Following the original order of three XHSL-1 units, the Navy was driven by urgency to immediately order more. In total another 160 units were ordered. Technical issues with production means that only 53 were ever delivered. Of these only a handful entered service, the rest went directly to storage and were then struck from the inventory.

Advertisement
Design features
  • Rectangular-section fuselage structure
  • Quadcycle landing gear
  • Stabilising fins at rear of fuselage
Description

The Bell HSL (Model 61) was an anti-submarine helicopter created by the Bell Helicopter company. It first took flight in 1953 and was introduced four years later in 1957.

The 1950s were a time when an urgent need for anti-submarine helicopters became apparent as both the USA and USSR engaged in the Cold War. The US navy held a design competition for such a helicopter and in 1950 Bell’s Model 61 was announced as the winner. Following this, three evaluation models were ordered. These were designated XHSL-1.

The Model 61 had a rectangular-section fuselage. It was powered by a massive single Pratt & Whitney R-2800 radial engine. The crew complement consisted of two pilots and two sonar operators. The landing gear consisted of a four-leg and six-wheel design.

The helicopter was meant to carry air-to-sea missiles and dipping sonar.

At the time the HSL was produced, it’s tandem-rotor design was the largest US helicopter example. It’s notable as being the only tandem-rotor helicopter Bell ever made.

Following the original order of three XHSL-1 units, the Navy was driven by urgency to immediately order more. In total another 160 units were ordered. Technical issues with production means that only 53 were ever delivered. Of these only a handful entered service, the rest went directly to storage and were then struck from the inventory.

- Advertisement -
Design features:
  • Rectangular-section fuselage structure
  • Quadcycle landing gear
  • Stabilising fins at rear of fuselage
Performance
Persons 16
Max. Range 350 mi
Cruise Speed 96 mph
Max. Speed 115 mph
Max. rate of Climb 0 ft/min
HOGE ceiling 0 ft
Service Ceiling 0 ft
Gross Weight 26500 lb
Empty Weigt 0 lb
Useful Load 0 lb
Dynamic system
Fuel Capacity 0 gallons
Number of Engines 1
Engine Type Piston
Engine Code Pratt & Whitney R-2800
Horse Power 2400
Rotorhead Teetering, tandem rotor configuration
Number of rotorblades 2
Rotor Diameter 49.21 ft
Number of tail rotorblades 2
Tailrotor Diameter 49.21 ft
Blueprints & model
